Standart Araç Özellikleri
| ARAÇ NUMARASI | DELİK BOYUTLARI ARALIĞI | ŞAFT ÇAPI | TOPLAM UZUNLUK | BOYUT A | BOYUT B | |||||
| İÇİNDE. | MM | İÇİNDE. | MM | İÇİNDE. | MM | İÇİNDE. | MM | İÇİNDE. | MM | |
| CP-04 | .062-.078 | 1.57-1.98 | 0.061 | 1.55 | 3.00 | 76.2 | 0.08 | 2.11 | 0.22 | 5.56 |
| CP-05 | .078-.094 | 1.98-2.39 | 0.077 | 1.96 | 3.00 | 76.2 | 0.08 | 2.11 | 0.22 | 5.56 |
| CP-06 | .093-.109 | 2.36-2.77 | 0.092 | 2.34 | 4.00 | 101.6 | 0.09 | 2.36 | 0.25 | 6.35 |
| CP-07 | .109-.125 | 2.77-3.17 | 0.108 | 2.74 | 4.00 | 101.6 | 0.09 | 2.36 | 0.25 | 6.35 |
| CP-08 | .125-.140 | 3.17-3.55 | 0.124 | 3.14 | 4.00 | 101.6 | 0.13 | 3.30 | 0.30 | 7.62 |
| CP-09 | .140-.156 | 3.55-3.96 | 0.139 | 3.53 | 4.00 | 101.6 | 0.13 | 3.30 | 0.30 | 7.62 |
| CP-10 | 0,156-.172 | 3.96-4.36 | 0.155 | 3.93 | 4.00 | 101.6 | 0.13 | 3.30 | 0.30 | 7.62 |
| CP-11 | .172-.187 | 4,36-4,74 | 0.171 | 4.34 | 4.00 | 101.6 | 0.13 | 3.30 | 0.30 | 7.62 |
| CP-12 | .187-.203 | 4.74-5.15 | 0.186 | 4.72 | 4.00 | 101.6 | 0.13 | 3.30 | 0.37 | 9.39 |
| CP-13 | .203-.219 | 5,15-5,56 | 0.202 | 5.13 | 4.00 | 101.6 | 0.13 | 3.30 | 0.37 | 9.39 |
| CP-14 | 0,219-.234 | 5.56-5.94 | 0.218 | 5.53 | 4.00 | 101.6 | 0.25 | 6.35 | 0.50 | 12.70 |
| CP-15 | 0,234-.250 | 5,94-6,35 | 0.233 | 5,91 | 4.00 | 101.6 | 0.25 | 6.35 | 0.50 | 12.70 |
| CP-16 | .250-.266 | 6,35-6,75 | 0.249 | 6.32 | 4.00 | 101.6 | 0.25 | 6.35 | 0.50 | 12.70 |
| CP-17 | 0,266-.281 | 6.75-7.13 | 0.265 | 6.73 | 4.00 | 101.6 | 0.25 | 6.35 | 0.50 | 12.70 |
| CP-18 | 0,281-.297 | 7,13-7,54 | 0.280 | 7.11 | 4.00 | 101.6 | 0.25 | 6.35 | 0.50 | 12.70 |
| CP-19 | .297-.313 | 7,54-7,95 | 0.296 | 7.51 | 4.00 | 101.6 | 0.29 | 7.36 | 0.54 | 13.71 |
| CP-20 | 0,313-.328 | 7,95-8,33 | 0.312 | 7,92 | 4.00 | 101.6 | 0.29 | 7.36 | 0.54 | 13.71 |
| CP-21 | .328-.343 | 8,33-8,71 | 0.327 | 8.30 | 4.00 | 101.6 | 0.29 | 7.36 | 0.54 | 13.71 |
| CP-22 | 0,343-.359 | 8.71-9.11 | 0.342 | 8.68 | 4.00 | 101.6 | 0.29 | 7.36 | 0.54 | 13.71 |
| CP-23 | 0,359-0,375 | 9.11-9.52 | 0.358 | 9.09 | 4.00 | 101.6 | 0.29 | 7.36 | 0.54 | 13.71 |
| CP-24 | 0,375-0,390 | 9.52-9.9 | 0.374 | 9,49 | 4.43 | 112.5 | 0.32 | 8.12 | 0.55 | 13.97 |
| CP-25 | .390-.406 | 9,9-10,31 | 0.389 | 9,88 | 4.43 | 112.5 | 0.32 | 8.12 | 0.55 | 13.97 |
| CP-26 | .406-.422 | 10.31-10.71 | 0.405 | 10.28 | 4.43 | 112.5 | 0.32 | 8.12 | 0.55 | 13.97 |
| CP-27 | .422-.437 | 10.71-11.09 | 0.420 | 10.66 | 4.43 | 112.5 | 0.32 | 8.12 | 0.55 | 13.97 |
| CP-28 | .437-.453 | 11.09-11.5 | 0.436 | 11.07 | 5,50 | 139.7 | 0.35 | 8.89 | 0.62 | 15.74 |
| CP-29 | .453-.468 | 11.5-11.88 | 0.452 | 11.48 | 5,50 | 139.7 | 0.35 | 8.89 | 0.62 | 15.74 |
| CP-30 | 0,468-.484 | 11.88-12.29 | 0.467 | 11.86 | 5,50 | 139.7 | 0.35 | 8.89 | 0.62 | 15.74 |
| CP-31 | .484-.500 | 12.29-12.7 | 0.483 | 12.26 | 5,50 | 139.7 | 0.35 | 8.89 | 0.62 | 15.74 |
| CP-32 | .500-.515 | 12.7-13.08 | 0.499 | 12.67 | 7,00 | 177.8 | 0.38 | 9,65 | 0.68 | 17.27 |
| CP-33 | .515-.531 | 13.08-13.48 | 0.514 | 13.05 | 7,00 | 177.8 | 0.38 | 9,65 | 0.68 | 17.27 |
| CP-34 | .531-.547 | 13.48-13.89 | 0.530 | 13.46 | 7,00 | 177.8 | 0.38 | 9,65 | 0.68 | 17.27 |
| CP-35 | .547-.563 | 13,89-14,3 | 0.545 | 13.84 | 7,00 | 177.8 | 0.38 | 9,65 | 0.68 | 17.27 |
| CP-36 | .563-.578 | 14.3-14.68 | 0.562 | 14.27 | 7,50 | 190.5 | 0.42 | 10.66 | 0.82 | 20.82 |
| CP-37 | .578-.594 | 14.68-15.08 | 0.577 | 14.65 | 7,50 | 190.5 | 0.42 | 10.66 | 0.82 | 20.82 |
| CP-38 | .594-.609 | 15.08-15.46 | 0.593 | 15.06 | 7,50 | 190.5 | 0.42 | 10.66 | 0.81 | 20.57 |
| CP-39 | .609-.625 | 15.46-15.87 | 0.608 | 15.44 | 7,50 | 190.5 | 0.42 | 10.66 | 0.81 | 20.57 |
| CP-40 | .625-.641 | 15.87-16.28 | 0.624 | 15.84 | 7,50 | 190.5 | 0.45 | 11.43 | 0.88 | 22.35 |
1.000 inç (25.4 mm) ‘ye kadar daha büyük delik boyutları için aletler mevcuttur; teklif isteyin.
