Talon Grip Vise Jaws
- Talongrip™ jaws suitable for 100mm, 150mm and 200mm vises
- Clamping capability up to 1.5mm allowing very aggressive machining
- Material savings with minimal holding allowance
GRIPLER & STOPERLAR |
| METRIK | ||||||||
| Parça No | Tanım | A | B | C | C1 | D | Sıkma Yüksekliği | Paketteki Adet |
| 33050 | Extra Grips | 19.05 | 12.7 | 6.35 | – | M5 | 1.5mm-1.9mm | 2 |
| 33020 | Extra Stop | 19.05 | 12.7 | 6.35 | 4.95 | M5 | – | 1 |
| 33030 | Extra Stop | 19.05 | 12.7 | 7.92 | 5.72 | M5 | – | 1 |
| 33075 | Fixture Grips | 19.05 | 19.05 | 7.92 | – | M5 | 1.5mm-3.0mm | 2 |
| 33100 | Fixture Grips | 19.05 | 25.4 | 7.92 | – | M5 | 1.5mm-3.0mm | 2 |
| 33150 | Fixture Grip | 25.4 | 25.4 | 12.7 | – | M5 | 1.5mm-5.6mm | 1 |
(32088) 8 ″ TalonGrip ™ Vise Çene Sistemi
| ÇELİK MENGENE ÇENE SETİ | ||||||||
| (4 X TalonGrips™, 1 x stop ve M5 civatalarını içerir) | ||||||||
| MONTAJ DELİKLİ | ||||||||
| Parça No | Mengene | A | B | C | D | E | ||
| 32044 | 100mm | 100 | 37.59 | 25.4 | 63.5 | 17.47 | ||
| 32066 | 100/150mm | 150 | 43.94 | 25.4 | 63.5/98.55 | 17.47/23.87 | ||
| 32068 | 150mm | 200 | 43.94 | 25.4 | 98.55 | 23.87 | ||
| 32088* | 150/200mm | 200 | 62.23 | 31.75 | 98.3/120.65 | 23.88/30.94 | ||
| MONTAJ DELİKSİZ | ||||||||
| Parça No | Vise | A | B | C | D | E | ||
| 33044 | – | 100 | 37.59 | 25.4 | – | – | ||
| 33066 | – | 150 | 43.94 | 25.4 | – | – | ||
| 33068 | – | 200 | 43.94 | 25.4 | – | – | ||
